Description
|
Projection System |
3LCD Technology, RGB liquid crystal shutter |
|
LCD Panel |
0.62 inch with C2 Fine |
|
Color Light Output |
4,100 Lumen- 2,300 Lumen (economy) In accordance with IDMS15.4 |
|
White Light Output |
4,100 Lumen – 2,300 Lumen (economy) In accordance with ISO 21118:2020 |
|
Resolution |
1080p |
|
Aspect Ratio |
16:9 |
|
Contrast Ratio |
16,000 : 1 |
|
Light source |
Lamp |
|
Lamp |
UHE, 230 W, 6,500 h durability, 17,000 h durability (economy mode) |
|
Keystone Correction |
Auto vertical: ±30 ° |
|
Colour Video Processing |
10 Bits |
|
Colour Reproduction |
Upto 1.07 billion colours |
|
Throw Ratio |
1.30 – 2.09:1 |
|
Zoom |
Manual, Factor:1 – 1.62 |
|
Screen Size |
31 inches – 304 inches |
|
Projection Distance Wide |
0.9 m – 8.9 m |
|
Projection Distance Tele |
1.4 m – 14.3 m |
|
Projection Distance Wide/Tele |
0.88 m – 14.29 m |
|
Projection Lens F Number |
1.51 – 1.77 |
|
Projection Lens Focal Length |
18.2 mm – 29.1 mm |
|
Projection Lens Focus |
Manual |
|
Offset |
10 : 1 |
|
Interfaces |
USB 2.0-A, USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in, Composite in, Miracast, Jack plug out, Jack plug in, Cinch audio in, Microphone input, Apple AirPlay 2 |
|
Network Protocol |
HTTPS, IPv6, SNMP |
|
Security |
Kensington lock, Padlock, Security cable hole, Password protection |
|
Other features |
A/V mute, AV Mute Slide, Auto Power On, Auto source search, Built-in speaker, Customizable user logo, Direct Power on/off, Document Camera Compatible, Home Screen, JPEG Viewer, Long lamp life, Microphone input, Network projection, OSD copy function, PC Free, Quick Corner, Schedule Function, Screen Mirroring, Split-Screen-Function, Volume control, Web Control, Web Remote, Wireless LAN capable, iProjection App |
|
Video Color Modes |
Blackboard, Cinema, Dynamic, Presentation, sRGB |
|
Power consumption |
284 Watt (Normal On-Mode), 181 Watt (Eco On-Mode), 332 Watt (Normal Peak-mode), 231 Watt (Eco Peak-Mode), 0.3 Watt (Energy saving standby) |
|
Supply Voltage |
AC 100 V – 240 V, 50 Hz – 60 Hz |
|
Product dimensions |
309 x 293 x 105 mm (Width x Depth x Height) |
|
Product weight |
3.1 kg |
|
Noise Level |
Normal:37 dB (A) – Economy:28 dB (A) |
|
Supported Temperature |
Storage -10° C – 60° C |
|
Supported Humidity |
Storage 10% – 90% |
|
Options |
Air filter, Ceiling mount, Document camera, External Speaker, Safety wire set, Soft carry case, Spare lamp, Suspension adapter |
|
Loudspeaker |
16 Watt |
|
Room Type / Application |
Boardroom, Gaming, Home Office, Huddle space / Portable, Large Meeting Room / Auditorium, Meeting room / Classroom |
|
Positioning |
Ceiling Mounted, Desktop |
|
Colour |
White |
